15
Repair Parts Listing
Key
Model No.
No. Description CF820ORG00 CF820PW00
* Hanger Pack, Consisting of: 761655-72 761655-73
1 Hanger Bracket (1) — —
2 Hanger Ball (1) — —
3 Downrod - 12” (1) — —
* Parts Bag Containing: 763488 763488
4 Pin, Clevis (1) — —
5 Clip, Hairpin (1) — —
6 Connector Wire Nut, 12 GA (5) — —
7 Threaded Stud, #8-32 x 1-1/4” (2) — —
8 Lockwasher, External Tooth #8 (2) — —
9 Knurled Knob, #8-32 (2) — —
10 Screw, Pan Head CR #10-32 x 8mm (21) — —
11 Washer, Flat #10 (21) — —
12 Screw, Oval Head CR 1/4-20 x 16mm (11) — —
13 Screw, Flat Head #8-32 x 10mm (4) — —
14 Screw, Pan Head & Lockwasher
#10-32 x 10mm (5) — —
15 Nut, 1/8-27 NPS (1) — —
16 Lockwasher, Split (1) — —
17 Balancing Kit (1) — —
18 Cover, Ceiling (1) 763472-ORB 763472-PW
19 Decorative Lower Scroll (1) 763530-ORB 763530-PW
20 Decorative Upper Scroll (1) 763529-ORB 763529-PW
21 Decorative Scroll Ends (3) 763474-ORB 763474-PW
22 Coupling Cover (1) 762463-ORB 762463-12
23 Upper Light Kit Assembly (1) 763536-ORB 763536-PW
24 Glass, Assembly Upper (1) 763534 763535
25 Flange Assembly (5 per set) 763480-ORB 763480-PW
26 Blade Assembly (5 per set) 763486-ORB 763486-PW
27 Harness, Wiring (Reverse Modular &
Aux. Capacitor) (1) 763528 763528
28 Housing, Switch Cup (1) 763484-ORB 763484-PW
29 Lower Light Fitter Assembly (1) 763531 763531
Washer, Rubber (1) — —
Washer, Flat (1) — —
Jamnut, Hex 1/8-27 NPS (1) — —
30 Glass, Lower Shade (1) 763482 763483
31 Cap, Finial (1) 763532-ORB 763532-PW
32 Nut, Finial (1) 763533-ORB 763533-PW
33 Receiver, Remote Control SW105 (1) 762401 762401
34 Transmitter, Remote Control SW116 (1)
& 3 Faceplates 763310 763310
35 Downrod, Short 6” (1) 761631-80 761631-81
— Owner’s Manual BP7351 BP7351
Before discarding packaging material, be certain all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION:
• PART NUMBER
• PART DESCRIPTION
• NAME OF ITEM • MODEL NUMBER
The model number of your Fan will be found on a label attached to the top housing.
For repair parts, phone 1-800-654-3545.
U.L. Model No.: CF820
