CWPAC

October 2012

4

www.EmersonProcess.com/Remote

ControlWave PAC

CPU Module

Processor

Type

586 CPU, 100 MHz

Memory

Boot

512 kB

Flash

32 MB on-board

SRAM

2 MB, battery backed

SDRAM

64 MB (66MHz SDRAM coupled to a 32-bit bus)

Clock

Accuracy

2 second/day at 25°C

Communications

COM1

Type

RS-232

Connector

PC/AT 9-pin male D-sub

Baud

Up to 115.2 KB

COM2

Type

RS-232

Connector

PC/AT 9-pin male D-sub

Baud

Up to 115.2 KB

COM3 (optional)

Type

RS 232 or RS 485

Connector

RJ45

Baud

Up to 115.2 KB

Isolation

500 Vdc (RS-485 only)

COM4 (optional)

Type

RS-485

Connector

PC/AT 9-pin male D-sub

Isolation

500 Vdc

Ethernet Port 1

Type

10/100 Base-T Ethernet port

Connector

RJ45

Isolation

500 Vdc

Inputs/Outputs

I/O Modules

AI

8 or 16 AI with local or remote automations. For more information, refer to

Product Data Sheet CWPAC:AIO

AO

4 or 8 AO with local or remote automations. For more information, refer to

Product Data Sheet CWPAC:AIO

AO with Read-Back

(for redundant I/O

systems only)

8 AO with local or remote automations. For more information, refer to

Product Data Sheet CWPAC:AIO

DI

16 or 32 DI with local or remote automations. For more information, refer

to Product Data Sheet CWPAC:DIO

DO

16 or 32 DI with local or remote automations. For more information, refer

to Product Data Sheet CWPAC:DIO
