Page 15
ETX-945 User Manual 1.02
www.diamondsystems.com
Page 15
4. INTERFACE CONNECTOR DETAILS
This section describes the functions available on all of the ETX-945
’s bus and I/O interface connectors. The ETX
3.0 specification, which provides more detail regarding the signals present on the ETX1, ETX2, ETX3, and ETX4
connectors, is available from the
ETX Industrial Group’s website
. Also
available from that site is the latest ETX Design Guide, which provides further details on the ETX connector signal
functions and interface considerations. Several other relevant specifications are referenced below.
