17
Technical Data
Appliance Class 2 sub class 1 and Class 1
Appliance category:
II 2H3+
Appliance gas supply: Natural Gas G20 20mbar
Hob
Rear left burner (semi-rapid) 2,000 W
Front left burner (ultra-rapid) 3,500 W
Rear right burner (semi-rapid) 2,000 W
Front right burner (auxiliary) 1,000 W
Oven
Electric Grill 1,800 W
Oven burner 3,000 W
Dimensions
Height 900 mm
Depth 600 mm
Width 497 mm
Oven Capacity 1.7 Cu. ft
Oven light 15 W
Supply voltage (50 Hz) 230-240 V
Instructions for the Installer
BURNER ULTRA-RAPID SEMI-RAPID AUXILIARY OVEN
(large) (medium) (small)
POSITION MAX MIN MAX MIN MAX MIN MAX MIN
NOMINAL THERMAL 3.5 1.2 2.0 0.45 1.0 0.33 3.0 1.0
POWER (kW)
NOMINAL FLOW
0.333 0.114 0.190 0.043 0.095 0.031 0.286 0.095
RATE (m 3 /h)
NOZZLE REFERENCE 136 Adjust. 96 Adjust. 70 Adjust. 116 Adjust.
(1/100 mm)
NOMINAL THERMAL 3.5 1.2 2.0 0.45 1.0 0.33 3.0 1.0
POWER (kW)
NOMINAL FLOW
252 86.5 144 32 72 24 216 72
RATE (g/h)
NOZZLE REFERENCE
9356 71 3 2 50 28 82 52
(1/100 mm)
NATURAL
GAS
20 mbar
TYPE OF
GAS
Characteristics
LPG GAS
28-30/37
mbar
VALUE
=
49.92
MJ/Kg
VALUE
=
37.78
MJ/m
3
Ws
-
50.7
MJ/
m
3
