Appendix A-7
LABELS AND PICTOGRAMS
Fig. 7 Pictogram Definitions (Continued)
KEEP ARMS
AND LEGS
WITHIN VEHICLE
F
TO OPERATE VEHICLE IN FORWARD:
✱ TURN KEY TO ON
✱ MOVE DIRECTION SELECTOR TO
FORWARD
✱ DEPRESS ACCELERATOR PEDAL
AND ACCELERATE SMOOTHLY
KEEP CLEAR
HAND OR
FINGERS CAN
BE TRAPPED
37.
38.
42.
P
F
R
TO OPERATE VEHICLE IN REVERSE:
✱ TURN KEY TO ON
✱ MOVE DIRECTION SELECTOR TO
REVERSE
✱ AN AUDIBLE DEVICE WILL SOUND
✱ DEPRESS ACCELERATOR PEDAL
AND ACCELERATE SMOOTHLY
TO LEAVE A GASOLINE POWERED
VEHICLE IN PARK:
✱ APPLY PARKING BRAKE
✱ TURN KEY TO OFF
✱ MOVE DIRECTION SELECTOR TO
FORWARD
P
N
TO LEAVE AN ELECTRIC POWERED
VEHICLE IN PARK:
✱ APPLY PARKING BRAKE
✱ TURN KEY TO OFF
✱ MOVE DIRECTION SELECTOR TO
NEUTRAL
39.
40.
41.
