Echo cs-520 User Manual
Page 5
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
LID, CLEANER
1
P021007150
1
KNOB, AIR CLEANER LID
1
A235000000
2
PLUG
1
13033832430
3
COVER, CYLINDER
1
A160000202
4
SCREW 5
3
16389038330
5
DEFLECTOR, HEAT
1
10152035430
6
GASKET, INTAKE
1
13001639930
7
ADAPTER, INTAKE
1
13051039932
8
SCREW 5X12
2
90023805012
9
INCLUDES ITEMS 9-11
INSULATOR KIT
1
13000038331
10
CUSHION
1
V420001130
11
NUT
2
13002033330
12
GASKET, INTAKE
1
13001038330
13
See Carburetor Diagram For Additional Information
CARBURETOR
1
------------------
14
PIPE, IMPULSE
1
13011038330
15
BRACKET, AIR CLEANER
1
13040538332
16
FILTER, AIR
1
13031038331
17
ELBOW, CARBURETOR
1
A204000004
18
SCREW 5X50
2
90016205050
19
CUSHION
1
13043038330
20
BRACKET
1
16381038933
21
ROD, THROTTLE
1
C454000041
22
GROMMET
1
17881014534
23
ROD, CHOKE
1
A241000100
24
SWITCH, IGNITION
1
16340038330
25
TERMINAL, SWITCH
1
16341338930
26
GROMMET
1
13211504920
27
PIPE, FUEL - SPIRAL
1
13201038331
28
CLIP
1
13201326630
29
FILTER, FUEL
1
13120519830
30
INCLUDES ITEMS 30-31
CAP ASY
1
13100437931
31
CONNECTOR, CAP
1
A365000050
32
O-RING 22
1
90072000022
33
99922204144
- 5 -
REVISED 03/19/08
CS-520 Chain Saw
Cylinder Cover, Intake, Fuel System, Ignition Switch
