Echo cs-520 User Manual

Page 23

background image

REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

AUTO-OILER ASY

1

43700238330

1

NEEDLE, ADJUST

1

43701638330

2

WASHER

1

43702937330

3

SPRING

1

43701537330

4

CAP, OIL PUMP

1

43706238330

5

PLUNGER

1

43702437330

6

SPRING

1

43701938330

7

CIRCLIP

1

12312715030

8

SCREW 4X16

2

90022304016

9

PLATE, SEAL

1

17531038330

10

PIPE, OIL OUTLET

1

43722938331

11

CLIP

2

13201326630

12

PIPE, OIL

1

43721038330

13

GROMMET

1

13211512330

14

FILTER, OIL

1

43620514730

15

INCLUDES ITEMS 10-13

OIL TANK ASY

1

43600539332

16

GASKET, OIL TANK

1

43601938330

17

SCREW 4X16

3

90016304016

18

VALVE, CHECK

1

43611413930

19

COLLAR

1

43601838330

20

INCLUDES ITEMS 15-16

CAP ASY

1

43600165631

21

CONNECTOR, CAP

1

A365000050

22

O-RING

1

90072502025

23

99922204144

- 23 -

REVISED 03/19/08
