REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

HANDLE, FRONT

1

C400000010

1

SCREW 5X16

2

9114505016

2

SCREW 5X20

2

9114505020

3

INCLUDES ITEMS 5-8

REAR HANDLE ASY

1

P021011460

4

VENT ASY

1

A356000030

5

COVER, VENT

1

13132840630

6

CLIP

1

13201326630

7

PIPE, VENT - GROMMET

1

13201239330

8

SCREW 5X16

3

90023805016

9

COVER

1

43304539332

10

CUSHION

2

10091038330

11

CAP, CUSHION

4

10091838330

12

SCREW

2

10091532530

13

CUSHION

4

10092138330

14

SCREW

2

10091533930

15

LOCKOUT, THROTTLE CONTROL

1

17809037930

16

TRIGGER, THROTTLE

1

C450000000

17

SPRING, THROTTLE RETURN

1

17804335430

18

SPRING PIN 4X30

1

90034540030

19

PLUG

1

V162000040

20

COVER, HANDLE

1

35115535430

21

SCREW 4X14

1

90025304014

22

GRIP, HANDLE

1

35111119830

23

SHIELD, SNOW

1

C418000000

24

99922204144

- 21 -

REVISED 03/19/08

Table of Contents

Part Number Index

CS-520 Chain Saw

Handles, Throttle Control
