Echo cs-520 User Manual
Page 15
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
INCLUDES ITEMS 2-26
CHAIN BRAKE ASY
1
43310039037
1
INCLUDES ITEMS 3-10
BRAKE LEVER ASY
1
43320139031
2
NUT 4
2
90050000004
3
WEIGHT, BRAKE
1
43317139330
4
SCREW 4X18
2
90023804018
5
SCREW 5X32
1
9131805032
6
SPACER
2
43316739130
7
SPRING
1
43311438331
8
FLANGE NUT 5
1
90056250005
9
PIN 3X24
1
90033030240
10
INCLUDES ITEMS 12-16
SPROCKET GUARD ASY
1
P021001280
11
GUARD, SPROCKET
1
43300539334
12
NOT REQUIRED
PLUG
1
V162000020
13
PLATE, SPROCKET GUARD
1
C305000001
14
SCREW 3X6
1
90022003006
15
SCREW 4X10
1
90025304010
16
ADJUSTER, BRAKE
1
43314235430
17
WASHER
1
V304000090
18
BAND, BRAKE
1
C328000060
19
SPRING PIN 2.5X12
1
90034225012
20
COVER, BRAKE
1
43331039330
21
SCREW 4X10
1
90025304010
22
STOPPER, BRAKE
1
43320935430
23
SPRING, BRAKE
1
43312235430
24
COLLAR 5.2X12X14
1
43311538330
25
LEVER, BRAKE
1
43320835431
26
SPRING PIN 4X8.8
1
90033040088
27
BOLT 5
1
V203000110
28
TENSIONER, CHAIN
1
C309000030
29
COLLAR
1
V355000270
30
GEAR, BEVEL
1
V651000011
31
GEAR, BEVEL
1
V651000001
32
FLANGE NUT 8
2
43301912330
33
PLATE, GUIDE - INNER
1
43301335431
34
SCREW 4X6
1
90022004006
35
INCLUDES ITEM 32
CHAIN CATCHER KIT
1
43300019831
36
SCREW 5X18
1
90022005018
37
SPIKED BUMPER KIT
1
88020038330
38
SCREW 5X12
2
90010505012
39
99922204144
- 15 -
REVISED 03/19/08
CS-520 Chain Saw
Chain Brake
