- 12 -

IMPORTANT: Make sure the negative battery cables are disconnected and
the battery charger used for charging the battery has an output of 16 volts and
7 amps or less to avoid damaging the battery (see chart below for
recommended charger settings).

Voltage

Reading

Percent

Charge

Maximum

Charger Settings

Charging Interval

12.6 or greater

100%

16 volts/7 amps

No Charging Required

12.4 – 12.6

75 – 100%

16 volts/7 amps

30 Minutes

12.2 – 12.4

50 – 75%

16 volts/7 amps

1 Hour

12.0 – 12.2

25 – 50%

14.4 volts/4 amps

2 Hours

11.7 – 12.0

0 – 25%

14.4 volts/4 amps

3 Hours

11.7 or less

0%

14.4 volts/2 amps

6 Hours or More

CAUTION

POTENTIAL HAZARD

If the ignition is in the “ON” position there is potential

for sparks and engagement of components.

WHAT CAN HAPPEN

Sparks could cause an explosion or moving parts

could accidentally engage causing personal injury.

HOW TO AVOID THE HAZARD

Be sure ignition switch is in the “OFF” position before

charging the battery.

3.2.3

Connect the negative battery cables.

NOTE: If the positive cable is also disconnected, connect the positive (red)

cable to the positive battery terminal first, then the negative (black) cable and
green/white wire to the negative battery terminal. Slip insulator boot over the
positive terminal.

NOTE: If time does not permit charging the battery, or if charging equipment
is not available, connect the negative battery cables and run the vehicle
continuously for 20 to 30 minutes to sufficiently charge the battery.

PART NO. 103-0315

LOCATION: Top Center of Console

Under Front of Seat

For Serial Nos. 251,999 and lower.

The machine is shipped with a dry battery.

3.2.1

Remove battery from machine. Tilt seat up to gain access to the battery.
Disconnect battery cables - negative(black) cable first. Remove battery
hold-down and lift battery out.

3.2.2

Place battery on a level surface and remove vent caps.
