11
P-TIMER
FREEZE
COMPUTER OMPUTER VIDEO
PAGE
SELECT
D.ZOOM
MUTE
VOLUME- MENU
NO SHOW
VOLUME+
KEYSTONE
AUTO PC
ON-OFF
Parts Name and Functions
To insure safe operation, please observe the following
precautions :
– Do not bend, drop the remote control, or expose the
Remote Control to moisture or heat.
– For cleaning, use a soft dry cloth. Do not apply
benzene, thinner, splay or any chemical material.
y
30 °
30 ° Point the remote control toward the projector
(Infrared Remote Receiver) when pressing any
button. Maximum operating range for the remote
control is about 16.4’ (5m) and 60° in front of the
projector.
16.4’
(5 m)
e
o i
!4
!5
u
t
r
!1
!3
!2
q POWER ON-OFF button
Turn the projector on or off. ( ☞ P17 )
w VIDEO button
Select VIDEO input source. ( ☞ P30 )
e COMPUTER button
Select COMPUTER input source. ( ☞ P22, P31 )
r MENU button
Open or close the On-Screen Menu. ( ☞ P18 )
t PAGE e ed d buttons
Scroll back and forth pages on the screen when giving a
presentation. (
☞ P9, P38 )
!0
y D.ZOOM e ed d buttons
Select the Digital zoom +/– mode and resize the image.
(
☞ P29 )
u AUTO PC button
Automatically adjust a computer image to its optimum
setting. (
☞ P24 )
i IMAGE button
Select the image level. (
☞ P27, P33 )
o FREEZE button
Freeze the picture. ( ☞ P20 )
!0 MUTE button
Mute the sound. ( ☞ P21 )
!1 P-TIMER button
Operate the P-timer function. ( ☞ P21 )
!2 NO SHOW button
Temporarily turn off the image on the screen. (
☞ P21 )
!3 KEYSTONE button
Correct keystone distortion. ( ☞ P20, P36 )
Operating Range
!4 POINT e ed d 7 7 8 8 ( VOLUME + / – ) buttons
– Select an item or adjust the value in the On-Screen
Menu. (
☞ P18 )
– Pan the image in Digital zoom +/– mode. ( ☞ P29 )
– Adjust the volume level. (the Point Left/Right buttons)
( ☞ P21 )
!5 SELECT button
– Execute the selected item. ( ☞ P18 )
– Expand / compress the image in Digital zoom mode.
(
☞ P29 )
q w
Remote Control
Pa
rt
Names and Functions
