Fitting the hob to the worktop
Before fitting the hob into the cut out, an
adhesive seal must be fitted to the underside
outside edge of the hob. It is essential that no
gaps are left in this seal in order to prevent
spillage near the hob seeping into the cabinet
below.
Proceed as follows:
1. Remove the pan supports, the burner caps
and crowns and turn the hob upside down,
taking care that the spark plugs and the
thermocouples are not damaged in this
operation.
2. Place the sealing gasket all around the glass
top edge as shown in Fig. 3.
3. Fit the hob in the cut out and push it down
until the glass top and the worktop make
contact, as shown in Fig. 4. The side springs
ensure centering.
A) Seal Fig. 4
Fig. 3
