Page 12: Gxt5vbatt battery cabinet - rear view
8
Figure 3
GXT5VBATTW120 battery cabinet with auxiliary 120 VAC
power - Rear view
Figure 4
GXT5VBATT battery cabinet - Rear view
208 VAC power from rear of
GXT5000R-208 to auxiliary power
input connector (see Figure 2)
DC cable from rear of
GXT5000R-208 to
external battery cabinet
(see Figure 2)
External battery
connectors
Auxiliary power
120 VAC @ 400 VA
with 4A circuit protector
Auxiliary power
input connector
External battery connectors
