Specifications
Transmission
• Two Hydro Gear variable displacement high
efficiency pumps independently coupled to two
high efficiency Parker/Ross wheel drive motors.
• Hydraulic Oil: Use Exmark Premium Hydro Oil.
• Hydraulic Oil Capacity: 2.4 qt. (2.2 L)
• Hydraulic Filter is replaceable cartridge type.
P/N 109-4180: 25 microns, 10 psi bypass
(Summer use above 32°F (0°C))
P/N 1-523541: 40 microns, 18 psi bypass (Winter
use below 32°F (0°C))
• Speeds:
– 0-8.0 mph (13 km/hr) forward.
– 0-4.0 mph (6 km/hr) reverse.
• Drive wheel release valves allow machine to be
moved when engine is not running.
Wheel Drive System
Drive wheels are direct coupled to Parker wheel drive
motors with 1 inch (25.4 mm) tapered shaft.
Tires & Wheels
Drive Front Caster
Pneumatic
(Air-Filled) Semi-
Pneumatic
Quantity 2 2
Tread K500 Smooth
Size 20 x 10.50–8 11 x 4.00-5
Ply Rating 4
Pressure 13 psi
(90 kPa)
Cutting Deck
• Cutting Width:
– 48 inch Deck: 48 inches (121.9 cm)
– 52 inch Deck: 52 inches (132.1 cm)
– 60 inch Deck: 60 inches (152.4 cm)
• Discharge: Side
• Blade Size: (3 ea.)
– 48 inch Deck: 16.25 inches (41.3 cm)
– 52 inch Deck: 18.00 inches (45.7 cm)
– 60 inch Deck: 20.50 inches (52.1 cm)
• Blade Spindles: Solid steel spindles with 1.00 inch
(25.4 mm) I.D. bearings.
• Deck Drive:
– Electric clutch mounted on engine shaft.
– Blades driven by one belt (w/self-tensioning
idlers).
• Deck: Full floating deck is attached to support
frame, removable for service. Deck design allows
for bagging, mulching or side discharge.
• Deck Depth:
– 48 inch Deck: 5.5 inches (14.0 cm)
– 52 inch Deck: 5.5 inches (14.0 cm)
– 60 inch Deck: 5.5 inches (14.0 cm)
• Cutting Height Adjustment:
Adjusts from 1 inch (2.5 cm) to 5 inches (12.7 cm)
in 1/4 inch (6.4 mm) increments
• Mulching Kit: Optional
• Bagger: Optional
Dimensions
Overall Width:
48 inch
Deck 52 inch
Deck 60 inch
Deck
Deflector
Up 51.8 inches
(131.6 cm) 56.3 inches
(143.0 cm) 63.9 inches
(162.3 cm)
Deflector
Down 59.6 inches
(151.4 cm) 64.8 inches
(164.6 cm) 72.8 inches
(184.9 cm)
Overall Length:
48 inch
Deck 52 inch
Deck 60 inch
Deck
Platform Up 60.5 inches
(153.7 cm)
60.5 inches
(153.7 cm) 62.4 inches
(158.5 cm)
Platform
Down 74.0 inches
(188.0 cm) 74.0 inches
(188.0 cm) 75.9 inches
(192.8 cm)
Overall Height:
48 inch Deck 52 inch Deck 60 inch Deck
50.0 inches
(127.0 cm) 50.0 inches
(127.0 cm) 50.0 inches
(127.0 cm)
