Edelbrock 33503 User Manual
Page 4
10(b) Front sway bar end links may now be reinstalled. Install both left and right at the same time. After both
sides are in position, the end link to control arm nuts can now be torqued to 16 ft. lbs.
10(c) Important: After all four shocks are installed, place jack or jack stand under control arm to support
vehicle and load suspension at ride height. Torque the shock mounting bolts to 80-100 ft. lbs.
This must be done to pre-load the bushing in their proper position for safe and proper handling. This is a
very important step.
10(d) Install and torque wheels to 90 ft. lbs. After 5-10 miles, re-torque wheels to 90 ft. lbs.
Parts List
Qty.
Description
Qty.
Description
2 #33506 Front shock assemblies
4
Upper coilover spring perch
2 #34506 Rear shock assemblies
1
Loctite tube
4 Lower spring seats
1
Anti-seize
2 Front lower rod ends (short threads)
2 Rear lower rod ends (long threads)
1
Hardware kit
4 - set screws
4 - 9/16 jam nuts
4 Coil over threaded sleeves
Enjoy the improved ride and handling from your new Edelbrock IAS shocks.
Edelbrock Corporation
2700 California Street
Torrance, California 90503
Toll-Free Tech Line (800) 416-8628
Tech Fax (310) 972-2730
Tech E-mail: [email protected]
P/N 84-8151
2001 Edelbrock Corporation
Revised 2/01
