6
ENVISION CONSOLE INSTALLATION MANUAL
NCS09-18
Overall Cabinet
Slope Top
Configuration
A B C D E F G H I J
Width Depth Height Grille Lid
Grille
Length
Grille
Width
in. 45.0 11.1 28.6 9.2 35.0 6.1 2.8 44.1 10.3 4.3
cm. 114.3 28.2 72.6 23.4 88.9 15.6 7.2 112.0 26.0 10.9
in. 50.0 12.6 29.1 9.2 35.0 6.1 2.5 49.1 11.8 4.3
cm. 127.0 32.0 73.9 23.4 88.9 15.6 6.4 124.7 29.8 10.9
09-12
15-18
@3;=D3>:/AB71AB@7>
4@=;0@=93@3>:/13=<0@=93<
3253=4:35/AA6=E<
6 7
8
1
4
3
/
2
5
0
@756B@3BC@<
B=>
4@=
:34B@3BC@<
23B/7:0
BE7AB3FB3<232B/0
0/19/<24=@B6CB/00@3/9A=44
=<:G0@3/9=44
B/0A/;3A723/A
5@7::3:72/AA6=E<
23B/7:/
BE7AB3FB3<232B/0
0/19/<24=@B6CB/00@3/9A=44
=<:G0@3/9=44
B/0A/;3A723/A
5@7::3:72/AA6=E<
@3;=D3>:/AB71AB@7>
4@=;0@=93@3>:/13=<0@=93<
3253=4:35/AA6=E<
0
/
47:B3@0@/193B 47:B3@0@/193B
Dimensional Data - Slope Top Cabinet
