7.7
Logic Summaries and Flow Charts (cont)
Logic AP - Logic AP (stepped automatic) is very similar to automatic (A) but has a higher
amount of safety. It has an increased amount of motion stop points.
Gate Status Result of Terminal
1 activation
Result of Terminal
2 activation
Result of Terminal
4 interruption Result of Terminal
5 interruption
Closed Opens leaf and re-closes after pause time No effect
Open and in
pause before
re-closing Stops operation No effect Re-loads pause time
Closing Re-opens leaf No effect Reverses direction of
motion
Opening Stops operation Stops motion and
reverses direction
after interruption
No effect
Stopped in mid
cycle Closes the leaf No effect
Logic EP - Logic EP (stepped semi-automatic) is designed to function similar to a garage door
opener. At full open the gate does not re-close after a pause time, it stays open until triggered to
re-close. Logic EP over-rides any set pause time.
Gate Status Result of Terminal
1 activation
Result of Terminal
2 activation
Result of Terminal
4 interruption Result of Terminal
5 interruption
Closed Opens leaf No effect
Open and in
pause before
re-closing Re-closes the leaf
Closing Stops operation No effect Reverses direction of
motion
Opening Stops operation Reverses direction
of motion
No effect
Stopped in mid
cycle Restarts motion in opposite direction the
gate was previously moving before
stopped in mid cycle
No effect
No effect
Gate Status Result of Termi-
nal 1 activation
Result of Termi-
nal 2 activation
Result of Termi-
nal 4 interruption Result of Terminal
5 interruption Result of Terminal
4&5 interrupted
simultaneous
Closed Opens leaf and re-closes after pause time No effect
Open and in
pause before
re-closing Stops operation No effect Re-loads pause time
Closing Re-opens leaf No effect Reverses direction of motion
Opening Stops operation Stops motion and
reverses direction
after interruption
No effect Reverses direction
of motion
Stopped in
mid cycle Closes the leaf No effect
Gate Status Result of Termi-
nal 1 activation
Result of Termi-
nal 2 activation
Result of Termi-
nal 4 interruption Result of Terminal
5 interruption Result of Terminal
4&5 interrupted
simultaneous
Closed Opens leaf No effect
Open and in
pause before
re-closing Re-closes the leaf No effect
Closing Stops operation No effect Reverses direction of motion
Opening Stops operation Reverses direction
of motion
No effect Reverses direction
of motion
Stopped in
mid cycle Restarts motion in opposite direction the
gate was previously moving before
stopped in mid cycle
No effect
