Estate E-SC 1102 - Manual (Page 32)

7.6
Logic Summaries and Flow Charts
Logic A - Logic A (automatic) is the most common setting. It automatically closes the gate de-
pending on the set pause time. This logic must be used in conjunction with the accessories: Free
Exit Sensor and Gate Timer.
Gate Status Result of Terminal
1 activation
Result of Terminal
2 activation
Result of Terminal
4 interruption Result of Terminal
5 interruption
Closed Opens leaf and re-closes after pause time No effect
Open and in
pause before
re-closing Re-loads pause time No effect Re-loads pause time
Closing Re-opens leaf No effect Stops motion and
reverses direction
after interruption
Opening No effect Reverses direction
of motion No effect
Stopped in mid
cycle Closes the leaf No effect
Logic S - Logic S (safety) is designed for higher control and accelerated levels of safety. By trig-
gering an opening device (i.e. push button, transmitter) the gate reverses directions preventing
foreseeable accidents.
Gate Status Result of Terminal
1 activation
Result of Terminal
2 activation
Result of Terminal
4 interruption Result of Terminal
5 interruption
Closed Opens leaf and re-closes after pause time No effect
Open and in
pause before
re-closing Re-closes the leaf No effect Closes after 5 sec-
onds
Closing Re-opens the leaf No effect Reverses direction of
motion
Opening Re-closes the leaf Reverses direction
of motion No effect
Stopped in mid
cycle Closes the leaf No effect
Gate Status Result of Termi-
nal 1 activation
Result of Termi-
nal 2 activation
Result of Termi-
nal 4 interruption Result of Terminal
5 interruption Result of Terminal
4&5 interrupted
simultaneous
Closed Opens leaf and re-closes after pause
time
No effect
Open and in
pause before
re-closing Re-loads pause time No effect Re-loads pause time
Closing Re-opens leaf No effect Stops motion and reverses direction after
interruption
Opening No effect Reverses direction
of motion No effect Reverses direction
of motion
Stopped in
mid cycle Closes the leaf No effect
Gate Status Result of Termi-
nal 1 activation
Result of Termi-
nal 2 activation
Result of Termi-
nal 4 interruption Result of Terminal
5 interruption Result of Terminal
4&5 interrupted
simultaneous
Closed Opens leaf and re-closes after pause
time
No effect
Open and in
pause before
re-closing Re-closes the leaf No effect Closes after 5 seconds
Closing Re-opens the leaf No effect Reverses direction of motion
Opening Re-closes the leaf Reverses direction
of motion No effect Reverses direction
of motion
Stopped in
mid cycle Closes the leaf No effect
