23
P
OWER
B
LOWER
O
PERATOR
’
S
M
ANUAL
S
PECIFICATIONS
PB-410
330 mm (13.0 in.) (w/o pipes)
440 mm (17.3 in.)
440 mm (17.3 in.)
9.6 kg (21.2 Ib.) (w/o pipes)
Air cooled, two-stroke, single cylinder gasoline engine
39.7 mL (2.42 cu. in.)
38.0 mm (1.50 in.)
35.0 mm (1.38 in.)
Walbro Diaphragm, model WT-684
Flywheel Magneto, capacitor discharge ignition type
NGK BPM-8Y Gap 0.65 mm (0.026 in.)
Spark Arrestor Muffler w / Catalyst
50:1 ratio with ECHO Power Blend X™ , ISO-L-EGD (ISO/CD 13738)
and JASO M345-FC/FD two-stroke, air-cooled engine oil.
Use 89 octane unleaded. Do not use fuel containing methyl alcohol,
more than 10% ethyl alcohol or 15% MTBE. Do not use alternative
fuels such as E-20 or E-85.
1.4 L (47.3 US fl. oz.)
Automatic Recoil Starter Centrifugal Type
7000 - 8000
2400 - 2800
9.0 m 3 /min. (318 cu. ft./min.)
74 (165 mph)
72 dB(A)
MODEL
Length
Width
Height
Mass (dry)
Engine Type
Displacement
Bore
Stroke
Carburetor
Ignition System
Spark Plug
Exhaust System
Mixture Ratio
Gasoline
Fuel Tank Capacity
Recoil Starter System
Wide Open Throttle Speed (r/min)
Idle Speed (r/min)
Maximum Air Volume
Maximum Air Speed w/pipes (m/s)
Sound Level at 50 ft. dB(A) scale per
ANSI B175.2
