1

SUP22200623

99922200623
11/08

9001014 C

RUISE

C

ONTROL

K

IT

I

NSTALLATION

I

NSTRUCTIONS

FOR

MODEL

PB-413T/PB-620

Please retain these instructions for future reference.

Tools Required: 5 mm hex wrench, screwdriver

Parts Required: PB-620 Cruise Control Handle Assembly

2 - Small plastic cable ties
1 - Large plastic cable tie

A

SSEMBLY

I

NSTRUCTIONS

Remove Old Throttle Control Handle Assembly

1. Disconnect spark plug lead (A), and pull lead out of upper cover

clamp (B) and lower cover clamp (C).

2. Remove 5 screws and remove engine cover (D).

3. Remove air filter cover and air filter (E).

4. Remove throttle cable/fuel line clamp screw and clamp (F).

5. Carefully cut plastic cable tie (G) securing throttle cable to fuel

lines.

B

E

G

E

H

D

A

D

C

F

I

H

G

L

M

F

F
