PAGE 8
EWP-2000 V2 User’s Manual
POWERING STATES
Powering On the EWP-2000 V2 from “Power Off” Mode
The battery shipped with your EWP-2000 V2 may be low in power – please be
prepared to use the AC-DC adapter while setting up the device for the first time
and to fully charge the internal battery pack.
The EWP-2000 V2 is delivered form the factory in a “Power Off” or “Reset
State”.
To start the EWP-2000 V2 for the first time, push and release the Power button
located on the left side of the device with the AC-DC adapter connected. The
display will come on in about 10 seconds. It will then take 50-60 seconds for
the Windows desktop to be displayed.
Powering Off the EWP-2000 V2 to “Standby” Mode
To turn the display off, push and release the power button on the left side.
Powering On the EWP-2000 V2 from “Standby” Mode
If for some reason the EWP-2000 V2 becomes unresponsive, press and hold the
power button on the left side of the display for 4 seconds. The display will go
out and the EWP-2000 V2 will reboot itself.
FRONT PANEL OVERVIEW
1 - Antenna 7 - Navigation
2 - Record LED 8 - Speakers
3 - Network LED 9 - Keyboard button
4 - Battery LED 10 - FireBall button
5 - Microphone 11 - Internet button
6 - Stylus 12 - Home button
Note: To increase and decrease the brightness of the display, press and hold
button “11” and then use button “7” to increase or decrease brightness level.
1
2
3 4 5
6
9 10 11 12
7
8
Setting Up The Web Pad
REAR PANEL OVERVIEW
1 - Compact Flash Card Reader
2 - Headphone jack
3 - Power On/Off
4 - AC Power In
5 - USB jack
USING THE DOCKING CRADLE
The EWP-2000 V2 is complemented by a desktop Cradle for support and
pass-through charging. On the cradle, you will find a power jack for the AC-
DC power adapter. Please seat the EWP-2000 V2 securely onto the cradle by
placing the web pad directly over the connectors in the top of the cradle and
inserting the web pad downward until the bottom of the web pad meets the
cradle.
You may charge the battery pack on the EWP-2000 V2 by connecting the
AC-DC adapter directly to the DC-in port on the EWP-2000 V2 or through the
power in port on the Cradle while the EWP-2000 V2 is docked on the Cradle.
1
2 3
4 5
