List of correspondence signals
The picture signal which can indicate a this machine is as it is the following table.
Correspondence signal
Resolution
(dot)
Scan rate Dot clock rate
(MHz)
Input format
Horizontal(kHz) Vertical(Hz)
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.73 59.94 - V
PAL/PAL-N/SECAM 720 x 576i 15.63 50.00 - V
525i (480i) 720 x 480 15.73 59.94 13.50 R/Y
625i (576i) 720 x 576i 15.63 50.00 13.50 R/Y
525i (480i) 720 (1440) x 480 i*2 15.73 59.94 27.00 D/H
625i (576i) 720 (1440) x 576i *2 15.63 50.00 27.00 D/H
525p (480p) 720 x 483 31.47 59.94 27.00 R/Y/D/H
625p (576p) 720 x 576 31.25 50.00 27.00 R/Y/D/H
750 (720) /60p 1280 x 720 45.00 60.00 74.25 R/Y/D/H
750 (720) /50p 1280 x 720 37.50 50.00 74.25 R/Y/D/H
1125 (1080) /60i *1 1920 x 1080i 33.75 60.00 74.25 R/Y/D/H
1125 (1080) /50i 1920 x 1080i 28.13 50.00 74.25 R/Y/D/H
1125 (1080) /24p 1920 x 1080 27.00 24.00 74.25 R/Y/D/H
1125 (1080) /24PsF 1920 x 1080i 27.00 48.00 74.25 R/Y
1125 (1080) /25p 1920 x 1080 28.13 25.00 74.25 R/Y/D/H
1125 (1080) /30p 1920 x 1080 33.75 30.00 74.25 R/Y/D/H
1125 (1080) /60p 1920 x 1080 67.50 60.00 148.50 R/Y/D/H
1125 (1080) /50p 1920 x 1080 56.25 50.00 148.50 R/Y/D/H
VESA400
640 x 400 31.47 70.09 25.18 R/Y/D/H
640 x 400 31.50 85.08 31.50 R/Y/D/H
VGA
640 x 480 31.47 59.94 25.18 R/Y/D/H
640 x 480 35.00 66.67 30.24 R/Y/D/H
640 x 480 37.86 72.81 31.50 R/Y/D/H
640 x 480 37.50 75.00 31.50 R/Y/D/H
640 x 480 43.27 85.01 36.00 R/Y/D/H
SVGA
800 x 600 35.16 56.25 36.00 R/Y/D/H
800 x 600 37.88 60.32 40.00 R/Y/D/H
800 x 600 48.08 72.19 50.00 R/Y/D/H
800 x 600 46.88 75.00 49.50 R/Y/D/H
800 x 600 53.67 85.06 56.25 R/Y/D/H
MAC16 832 x 624 49.72 74.55 57.28 R/Y/D/H
852 x 480 852 x 480 31.47 59.94 34.24 D/H
XGA
1024 x 768 39.55 50.00 51.89 D/H
1024 x 768 48.36 60.00 65.00 R/Y/D/H
1024 x 768 56.48 70.07 75.00 R/Y/D/H
1024 x 768 60.02 75.03 78.75 R/Y/D/H
1024 x 768 65.55 81.63 86.00 R/Y/D/H
1024 x 768 68.68 85.00 94.50 R/Y/D/H
WSVGA 1066 x 600 37.64 59.94 53.00 D/H
MXGA
1152 x 864 53.70 60.00 81.62 D/H
1152 x 864 63.99 70.02 94.20 R/Y/D/H
1152 x 864 67.50 75.00 108.00 R/Y/D/H
1152 x 864 77.09 85.00 119.65 R/Y/D/H
MAC21 1152 x 870 68.68 75.06 100.00 R/Y/D/H
1280 x 720 1280 x 720 44.76 60.00 74.48 R/Y/D/H
1280 x 768
1280 x 768 39.55 49.94 65.18 R/Y/D/H
1280 x 768 47.70 60.00 80.14 R/Y/D/H
1280 x 768 47.78 59.87 79.50 R/Y/D/H
1280 x 800
1280 x 800 41.20 50.00 68.56 R/Y/D/H
1280 x 800 49.31 59.91 71.00 R/Y/D/H
1280 x 800 49.70 59.81 83.50 R/Y/D/H
MSXGA
1280 x 960 60.00 60.00 108.00 R/Y/D/H
1280 x 960 85.94 85.00 148.50 R/Y
SXGA
1280 x 1024 63.98 60.02 108.00 R/Y/D/H
1280 x 1024 79.98 75.02 135.00 R/Y/D/H
1280 x 1024 91.15 85.02 157.50 R/Y/D/H
1360 x 768
1360 x 768 47.71 60.02 85.50 D/H
1360 x 768 47.70 60.00 84.72 D/H
1360 x 768 47.72 59.80 84.75 D/H
1366 x 768
1366 x 768 39.55 50.00 69.92 D/H
1366 x 768 48.39 60.03 86.71 R/Y/D/H
1366 x 768 48.00 60.00 72.00 R/Y/D/H
1366 x 768 39.56 49.89 69.00 R/Y/D/H
1366 x 768 47.71 59.79 85.50 R/Y/D/H
SXGA+
1400 x 1050 65.22 60.00 122.61 D/H
1400 x 1050 82.20 75.00 155.85 R/Y/D/H
WXGA+
1440 x 900 55.47 59.90 88.75 R/Y/D/H
1440 x 900 55.92 60.00 106.47 R/Y/D/H
1600 x 900
1600 x 900 46.30 50.00 97.05 D/H
1600 x 900 60.00 60.00 108.00 D/H
1600 x 900 55.99 59.95 118.25 D/H
1600 x 900 55.92 60.00 119.00 D/H
WSXGA+ 1680 x 1050 65.29 59.95 146.25 R/Y/D/H
UXGA 1600 x 1200 *3 75.00 60.00 162.00 R/Y/D/H
1920 x 1080
1920 x 1080 *4 66.59 59.93 138.50 R/Y/D/H
1920 x 1080 67.50 60.00 148.50 R/Y/D/H
WUXGA 1920 x 1200 *3 74.04 59.95 154.00 R/Y/D/H
● The signal format distinguished automatically will be sometimes indication different from an actual input signal.
*1: When 1125 (1035) /60i signal is input, it is displayed as 1125 (1080) /60i signal. *3: Displayed with image elements thinned out in the image processing circuit.
*2: Pixel-Repetition signal (dot clock frequency 27.0 MHz) only
*4: Based on VESA CVT-RB (Reduced Blanking) standard
V：VIDEO
R：D-sub RGB
Y：YC
B
C
R
/YP
B
P
R
D：DVI-D
H：HDMI
