West Penn 994 14 AWG 2-Conductor Unshielded Fire Alarm Cable (1000', Red) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 2
• AWG Size 14
• Conductor Stranding Solid
• Conductor Type Bare Copper
• Nominal DCR 2.6 Ohm/1000ft
• Cabling Lay Length 3.5 in
• Twists/Foot 3.4 twist/ft
INSULATION PARAMETER -
• Insulation Type Thermoplastic - PP
• Insulation Thickness 0.01 in
• Insulation Color Code 1. Black 2.Red
SHIELDING PARAMETER -
• Shield Type None
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 23 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type PVC
Jacket Thickness 0.022 in
Nominal Cable O.D. 0.222 in
Plenum No
NEC UL Rating FPLR
RoHS Compliant Yes
Pull Tension 99 lbs
Bend Radius 1.998 in
Cable Weight 41 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability UL1666 Vertical Shaft
Operating Range -20 to 75 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
994
Fire Alarm Signaling
14/2 Solid Unshielded FPLR
Toll Free: 800-245-4964 | [email protected] | www.westpennwire.com
