West Penn Plenum-Rated 60990B 16 AWG 2-Conductor Shielded Fire Alarm Cable (1000', Red) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 2
• AWG Size 16
• Conductor Stranding Solid
• Conductor Type Bare Copper
• Nominal DCR 4.1 Ohm/1000ft
• Cabling Lay Length 2 in
• Twists/Foot 6 twist/ft
INSULATION PARAMETER -
• Insulation Type Plenum PVC
• Insulation Thickness 0.008 in
• Insulation Color Code 1. Black 2.Red
SHIELDING PARAMETER -
• Shield Type Overall 100% Aluminum Foil
• Drain Wire Type Tinned Copper
• Drain Wire AWG 24 AWG
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 77 pF/ft
• Nom. Cap. Conductor to Shield 139 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type Flexible Plenum
Jacket Thickness 0.015 in
Nominal Cable O.D. 0.168 in
Plenum Yes
NEC UL Rating FPLP
RoHS Compliant Yes
Pull Tension 76 lbs
Bend Radius 1.512 in
Cable Weight 29 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability NFPA 262 Plenum
Operating Range -0 to 75 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
60990B
Fire Alarm Signaling
Toll Free: 800-245-4964 | [email protected] | www.westpenn wire .com
16/2 Solid Shielded FPLP
