West Penn Plenum-Rated 60991B 16 AWG 2-Conductor Unshielded Fire Alarm Cable (1000', Red) - Manual

CONSTRUCTION & DIMENSIONS -
CONDUCTOR PARAMETER -
• Number of Conductors 2
• AWG Size 16
• Conductor Stranding Solid
• Conductor Type Bare Copper
• Nominal DCR 4.1 O hm/1000ft
• Cabling Lay Length 2.75 in
• Twists/Foot 4.4 twis t/ft
INSULATION PARAMETER -
• Insulation Type Plenum PVC
• Insulation Thi kness 0.008 in
• Insulation Color Code 1. Black 2.Red
SHIELDING PARAMETER -
• Shield Type None
ELECTRICAL CHARACTERISTICS -
• Nom. Cap. Between Conductors 33 pF/ft
OVERALL CONSTRUCTION PARAMETERS -
Jacket Type Flexible Plenum
Jacket Thi kness 0.015 in
Nominal Cable O.D. 0.164 in
Plenum Yes
NEC UL Rating FPLP
RoHS Compliant Yes
Pull Tension 62 lbs
Bend Radius 1.476 in
Cable Weight 26 lbs
OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS -
UL Flammability NFPA 262 Plenum
Operating Range -0 to 75 Deg C
UL Voltage Rating 300
Construction & Dimensions
Overall Construction
Overall Electrical & Optical Characteristics
Detailed Specification & Technical Data
60991B
Fire Alarm Signaling
16/2 Solid Unshielded FPLP
Toll Free: 800-245-4964 | [email protected] | www.westpennwire.com
