218

Technical Notes

➜

NIKKOR Z 24–70mm f/4 S Lens User’s Manual

1 Lens hood

Lens hoods block stray light that would
otherwise cause flare or ghosting. They also
serve to protect the lens.

2 Lens hood lock mark

Use when attaching the lens hood.

3 Lens hood alignment

mark

4 Lens hood mounting

mark

Use when attaching the lens hood.

5 Zoom ring

Rotate to zoom in or out. Be sure to extend the
lens before use.

6 Focal length scale

Determine the approximate focal length when
zooming the lens in or out.

7 Focal length mark

8 Control ring

•

Autofocus mode selected

: In autofocus mode, you

can rotate this customizable ring to perform a
function selected with the camera.

•

Manual focus mode selected

: Rotate to focus.

9 Lens mounting mark

Use when mounting the lens on the camera.

10 Rubber lens-mount

gasket

—

11 CPU contacts

Used to transfer data to and from the camera.

12 Focus-mode switch

Choose

for autofocus,

for manual focus. Note

that regardless of the setting chosen, focus must
be adjusted manually when manual focus mode
is selected using camera controls.

13 Front lens cap

—

14 Rear lens cap

—
