Setting Up the Monitor

│

37

Connecting the DisplayPort (DisplayPort to DisplayPort) Cable

NOTE: The default out of factory setting is DP1.4 (DP1.2 is supported).

If the monitor fails to show any content after the DisplayPort cable is
connected, follow the procedures below to change the settings to
DP1.1:

• Press the Joystick to open the Menu Launcher.

• Toggle the Joystick to select Input Source

.

• Toggle the Joystick to highlight DP

.

• Press and hold the Joystick for approximately 10 seconds, and the DisplayPort

configuration message appears.

• Toggle the Joystick to select

Yes

and then press the Joystick to save the

changes.

Repeat the above steps to change the DisplayPort format settings if
necessary.
