Operating

your

monitor |

39

Auto Adjust

Use this key to activate automatic setup and adjust menu.

Dell P2418HZ Energy Use

Press to adjust the screen automatically.

Auto Adjust

Input Source

Color

Display

Energy

Menu

Others

Brightness / Contrast

Resolution: 1920x1080, 60Hz

The following dialog appears on a black screen as the
monitor self-adjusts to the current input:

Auto Adjustment in Progress...

Auto adjustment allows the monitor to self-adjust to the
incoming video signal. After using auto adjustment, you
can further tune your monitor by using the pixel clock
(coarse) and phase (fine) controls under display settings.

NOTE

: Auto adjust does not occur if you press the

button while there are no active video input signals or
attached cables.

This option is only available when you are using the
analog (VGA) connector.
