LOCATION OF CONTROLS AND INDICATORS
1.) PHONES Jack.
2.) Speaker.
3.) LCD CLOCK.
4.) VOLUME Control.
5.) Dial Pointer.
6.) TUNING Control.
7.) (AM-FM/TV1-TV2) BAND
Selector Switch.
8.) POWER ON/OFF Switch.
9.) Carrying Handle (Back Cabinet).
10.) FM/TV/Weather Band Telescopic
Antenna.
11.) WEATHER BAND FINE TUNING
Control (Back Cabinet).
12.) Battery & AC Cord Compartment.
(Back Cabinet).
13.) Display Back LIGHT Button.
14.) Clock MODE Button.
15.) Clock SET Button.
16.) WEATHER Band Button.
Front Panel
5
9 10 11
2
4
1
7
8
12
13
14
6
15
3
Top Panel
16
