Emerson Radio HR2001 - Manual

Thank you......................
for purchasing this Emerson Digital Tuning Personal Stereo Radio with Lightweight In-Ear Type Stereo Phones. This ultra compact stereo
receiver lets you enjoy your favorite radio stations while keeping your hands free for other activities. And you can enter up to 20 of your
favorite stations (10 FM and 10 AM) in the tuner memory for easy recall at the touch of a button. Switch on the BBS (Bass Boost) Control
and you won't believe you're listening to a system that fits in the palm of your hand. For the fashion conscious we've included two additional
color snap-on front panels so you can coordinate your radio with your mood, or whatever you're wearing. Please read this instruction sheet
carefully and completely to make sure you understand the operation of your personal stereo receiver, and save this sheet for future
reference. If you encounter any problems with the set up or operation of this radio, please call the Emerson Radio Corp. Customer Service
Hotline, toll free, at 1-800-898-9020.
A Word Of Caution
Use good common sense when using this or any other headphone system. Adjust the volume to a comfortable level. Continuous listening
to music through headphones at high volume levels can be detrimental to your hearing. Also, do not set the volume to such a high level
that it prevents you from hearing other sounds, such as approaching cars, etc.
LOCATION OF CONTROLS AND INDICATORS
Visit our web site at www.emersonradio.com
Battery Installation
1.) Hold the radio upside down and slide the battery compartment door in the direction
of the arrow until the door pops open.
2.) Insert two ‘AAA’ size batteries (not included), following the polarity diagram shown
at right. We recommend using alkaline batteries for longest life.
3.) Push the battery compartment door closed and slide it back opposite the direction
of the arrow.
Memory backup
In order to maintain the memories when installing new batteries, the unit must be
turned off and new batteries installed within 1 minute.
1.) LOCK ON/OFF Switch.
2.) Headphone Jack.
3.) TUNING DOWN Button.
4.) TUNING UP Button.
5.) MEM.CH and Buttons.
6.) MEM. (Memory) Button.
7.) BAND (AM/FM) Button.
8.) LCD Display.
9.) Battery Compartment (Bottom cabinet).
10.) VOLUME Control.
11.) POWER ON/OFF Switch.
12.) BBS (Bass Boost) ON/OFF Switch.
13.) Belt Clip.
Removing The Belt Clip
To r e m o v e t h e b e l t c l ip , s l i d e i t
downward in the direction of the arrows.
Changing The Front Panel
• To remove the front panel gently pry it up from the bottom edge as shown.
• To replace the front panel, place it on the front of the radio and press down on the panel
at (1) Right side first and then (2) Left side until it snaps into place.
NOTE: If the batteries are changed while the POWER switch is 'ON', the display may not reappear immediately. If this occurs, slide the
POWER switch to the 'OFF' position, and then back to the 'ON' position to restore the display.
11
12
13
10
3
7
8
9
2
1
5 4
6
Listening to the Radio
1.) Insert the headphone plug into the headphone jack. The headphone wire serves as the FM antenna.
2.) Set the VOLUME control to a low setting.
3.) Press the BAND button to select AM or FM station, as desired.
MODEL:
HR2001
AM/FM PLL STEREO RADIO
