Kodak i2420 - Manual (Page 11)

8 A-61756 May 2014
Specifications Following are specifications for the Kodak Legal Size Flatbed
Accessory.
Scanning Technology CIS Image Sensor
Color bit depth: 24-bit
Optical Resolution 1200 dpi
Image Processing
features Based on the ADF Scanner capabilities
Maximum Thickness up to 40.6 mm (1.6 in.)
Maximum Document Size 216 x 356 mm (8.5 x 14 in.)
Recommended Daily
Volume 100 pages per day
Illumination 3 Color LED
Scanner Dimensions Height: 43.7 mm / 1.7 in.
Length: 470.5 mm / 18.5 in.
Width: 268 mm / 10.5 in.
Flatbed Weight - without
power adapter 2.72 kg (6 lbs)
Host Connection USB 2.0
Operating Temperature 10°C to 35°C (50 to 95°F)
Operating Humidity 15 to 80% RH
Power Consumption -
Scanner Sleep mode: <4.3 watts
Acoustic Noise
(Sound Power level) Operating: less than 70 dB
Off mode or Ready mode: less than 46 dB
Electrical rating 12 Vdc 1.5 A
Electrical requirement 100 - 240 V (international) 50/60 Hz
