PLANET IPX-1500 - Manual (Page 54)

Parameter Description
Extension No.
The range is 100~899 and you are free to assign any number in this range to
an extension. If two or more extensions are assigned the same number, the
system will try to transfer the call to the one with the lowest physical port
number first. If that extension busy, the system will then try the one with the
second lowest port number, and so on.
Phy line The physical line number of the extension
Password
Please insert the four-digit number. This password is used in the Usage
Control function described below.
Answer Group
Priority of CO line answering group, The left one will be the first CO group to
answer, selecting “00” will disable the answer group setting
Dial out Group
Priority of CO line dial-out group. The left one will be the first CO group to
dialout, selecting “00” will disable the dial-out group setting
Out call control mode Long distance call access control via locking extension number or password
54
