Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its
respective corporation.
Features and Design . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . .
To the Owner . . . . . . . . . . . . . . . . . . . .4
Safety Instructions . . . . . . . . . . . . . . .5
Air Circulation 6
Installing the Projector in Proper
Position 6
Moving the Projector 6
Compliance . . . . . . . . . . . . . . . . . . . . .7
Part Names and Functions . . . . . . . .8
Front 8
Back 8
Bottom 8
Rear Terminal 9
Top Control 10
Remote Control 11
Remote Control Battery Installation 12
Operating Range 12
Installation . . . . . . . . . . . . . . . . . . . . . .1
Positioning the Projector 13
Adjustable Foot 13
Using the ferrite core 14
Connecting the AC Power Cord 14
Connecting to a Computer 15
Connecting to Video Equipment 16
Connecting to Component Video
and RGB (Scart) Equipment
17
Basic Operation . . . . . . . . . . . . . . . . .18
Turning On the Projector 18
Turning Off the Projector 20
How to Operate the On-Screen Menu 21
Menu Bar
22
Zoom and Focus Adjustment 23
Auto setup function 23
Keystone Correction 23
Sound Adjustment 24
Remote Control Operation 24
Computer Input . . . . . . . . . . . . . . . . .26
Input Source Selection 26
Computer System Selection 27
Auto PC Adjustment 28
Manual PC Adjustment 29
Image Level Selection 31
Image Level Adjustment 33
Screen Size Adjustment 34
Video Input . . . . . . . . . . . . . . . . . . . . .7
Input Source Selection (Video) 37
Input Source Selection
(S-video, Component, RGB Scart 21-pin)
38
Video System Selection 39
Image Level Selection 40
Image Level Adjustment 42
Screen Size Adjustment 44
Setting . . . . . . . . . . . . . . . . . . . . . . . . .45
Setting 45
Maintenance and Cleaning . . . . . . . .57
Warning indicator 57
Cleaning the Air Filter 58
Attaching the Lens Cover 58
Cleaning the Projection Lens 59
Cleaning the Projector Cabinet 59
Lamp Replacement 60
Resetting the Lamp Counter 62
Appendix . . . . . . . . . . . . . . . . . . . . . . .6
Troubleshooting 63
Menu Tree 66
Indicators and Projector Condition 69
Compatible Computer Specifications 70
Technical Specifications 71
Optional Parts 72
Configurations of Terminals 73
Dimensions 73
PIN Code Number Memo
74
