Physical/Environmental Specifications
Single-Port Power Over Ethernet Adapter User’s Guide A-3
Physical/Environmental Specifications
Table A‐1 provides physical and mechanical specifications for the
Single‐Port Power Over Ethernet Adapter.
Input:
AC Input Voltage Range
90 to 264VAC
AC Input Voltage Rating
100 to 240VAC
AC Input Current
0.5A(RMS) max. for 90VAC
0.35A(RMS) max. for 240VAC
Leakage Current
0.25mA max. @ 254VAC 60Hz
AC Input Frequency
47‐63Hz
Table A-1 Physical and Mechanical Specifications
Item Specification
Length: 140 mm (5.51 in.)
Width: 65 mm (2.55 in.)
Height: 36 mm (1.42 in.)
Weight: 0.2 Kg (0.44 lb)
