Magnetic Products, Inc.

683 Town Center Drive,

Highland, MI 48357

Tel: 248-887-5600

Email: [email protected]Website: www.mpimagnet.com

Cassel Metal Shark® Dividable Conveyor Metal Detectors

List Price QUOTE

Cassel Metal Shark® Dividable Conveyor Metal Detectors

The METAL SHARK® Dividable Conveyor Metal Detector features a dividable sensor head, enabling easy integration
onto an existing conveyor without cutting the belt.

MPI is the exclusive North American distributor for Cassel metal detectors and checkweighers for the food,
pharmaceutical, plastics, aggregate, recycling and mining industries.

·

APPLICATIONS

·

FEATURES AND BENEFITS

·

SENSOR HEAD

·

CONTROLLER

APPLICATIONS

• Plastic recycling
• Rubber production
• Wood and paper processing
• Food products

FEATURES AND BENEFITS

• Shortest metal-free zone in the industry!
• Stainless steel housings
• Most technologically advanced metal detector available
• Extremely accurate and stable metal detector
• Easy to install onto conveyors
• Superior performance
• Up to 6000 FPM scanning speed with 100% accuracy
Aperture height can be changed: the metal detector automatically calibrates for changes in sensor head geometry.

No maintenance electronics: automatic balance and calibration of electronics ensure many years of reliable performance. After initial set-up, no further adjustment of
metal detector electronics is needed.

Outstanding stability and sensitivity: new "recipes" or changes to current data are easily programmed. Digital noise filters eliminate any undesired signals, while
multichannel technology provides optimum detection of ferrous, nonferrous or stainless steel contaminants. The integrated sensor is built to withstand the rigors of a
harsh production setting. Key internal electronics are fully protected within the metal detector and reliably perform in extreme environments.

High-speed Digital Signal Processor (DSP): highly effective high-speed processors support digital filters to provide more efficient product effect-compensation and
more effective noise reduction, allowing identification of even the smallest metal particles by the metal detector.

Direct Digital Synthesizer (DDS): Direct Digital Synthesizer (DDS) replaces traditional quartz or analog oscillating chips used to generate frequency by digitally
generating a consistently stable frequency and phase preventing drift.

SENSOR HEAD

Digital Metal Detector for conveyor applications with stainless steel housing fabricated to IP69k
Digital Balance Control adjusts for temperature and humidity fluctuations by monitoring coil balance more than 200 times per second
Digital Frequency Control utilizes digital synthesizer technology to generate a constant and stable frequency and phase, during extended metal detector use
Digital Dynamic Noise Filter reduces or eliminates electronic and vibration signals in the environment, creating a more reliable signal

CONTROLLER

4/22/2014 | Page 1 of 2
