Magnetic Products 300 Series, Rare Earth Plate Magnets (NP Series) User Manual
Specifications
Magnetic Products, Inc.
683 Town Center Drive,
Highland, MI 48357
Tel: 248-887-5600
Email: [email protected] • Website:
Item # 300 Series, Rare Earth Plate Magnets (NP Series)
List Price QUOTE
Application:
MPI Rare Earth Plate Magnets remove both large and small pieces of tramp iron from product processing flows. The powerful permanent Rare Earth magnet material
provides more effective separation performance for a broader range of applications, including product flows with deeper burden depths.
MPI Rare Earth Plate Magnets provide increased magnetic strength for effective tramp metal separation on product flows. Neodymium-Iron-Boron magnetic material
minimizes product "wash-off" for below-the-flow installations.
Operation:
The magnetic face consists of two 430 series stainless steel poles that are spaced either to 1) effectively increase holding values on a Holding Plate Magnet or 2)
achieve maximum reachout values for the reachout Plate Magnet. MPI Neo Plate Magnets are easy to install. The hinged mounting design allows quick and rapid
cleaning of the magnetic surface. The strong magnetic field is effective in product streams up to 6".
Standard features:
• Stainless steel heavy-duty hinges and latches, with mounting hardware for easy installation and maintenance
• Powerful Rare Earth Neodymium-Iron-Boron permanent magnet material
• Operating temperatures up to 250 deg. F
• 100% stainless steel construction
• 1" wide uniform sealing flange to prevent product leakage
• Rugged all-welded construction
Optional features:
• Samarium cobalt magnetic material for high operating temperatures
• Waterproof, weather-resistant enclosure
• Replaceable abrasive resistant face plates
• Non-standard sizes
SPECIFICATIONS
4/20/2014 | Page 1 of 2
