Magnetic Products, Inc.

683 Town Center Drive,

Highland, MI 48357

Tel: 248-887-5600

Email: [email protected]Website: www.mpimagnet.com

Cassel Metal Shark® Metal Detector for Liquid and Slurries

List Price QUOTE

Cassel Metal Shark® Metal Detector for Liquid and Slurries

This metal detector is typically used with fluid and paste-like products, and is appropriate for the food industry to ensure
food safety. Boasting a sturdy stainless steel sensor and control unit housing, maintenance-free design and high quality
construction, users benefit from reliable metal detector operation in even the most challenging industrial environments.

MPI is the exclusive North American distributor for Cassel metal detectors and checkweighers for the food,
pharmaceutical, plastics, aggregate, recycling and mining industries.

·

SENSOR HEAD

·

CONTROLLER

·

RUGGED THROUGHPUT HOSE

·

METAL DETECTOR REJECT

SYSTEMS

·

NO MAINTENANCE ELECTRONICS

·

HACCP COMPLIANCE

SENSOR HEAD

Digital Metal Detector for conveyor applications with stainless steel housing fabricated to IP69k
Digital Balance Control adjusts for temperature and humidity fluctuations by monitoring coil balance more than 200 times per second
Digital Frequency Control utilizes digital synthesizer technology to generate a constant and stable frequency and phase, during extended metal detector use
Digital Dynamic Noise Filter reduces or eliminates electronic and vibration signals in the environment, creating a more reliable signal
• Stainless steel pneumatic reject device for powder and bulk products

CONTROLLER

• SHARK-2 Digital Control housed inside a stainless steel enclosure, fabricated up to IP69k
• 5.4” color screen with soft menu keypad to be attached to wall
• Intuitive user interface allows operators to quickly and easily control metal detector
• Exclusive Four-Quadrant Digital Technology allows for a 360º freestyle teach area around the product effect, significantly increasing metal detector sensitivity
• Quick-Teach with graphic assist allows the metal detector to be operational in less than 10 product passes
• Auto reporting - HACCP-GMP-IFS5, operating data and Ethernet option included
• Four-level password feature-operator, manager, technician and service
• Performance Validation Software (PVS Test) automatically notifies operator to test metal detector
• Product presets allow for quick changing of product settings when changing products

RUGGED THROUGHPUT HOSE

• Metal detector pipe diameters range from 1-1/2" to 4"
• Designed for a harsh plant environment
• Withstands up to 220 psi

METAL DETECTOR REJECT SYSTEMS

• Two-way butterfly valve pneumatic reject system for quick reject of metal contamination (Other reject systems available)
• Air pressure monitor ensures that reject mechanism has air pressure and can stop upstream equipment if pressure is lost
• Easy integration to existing system with weld-on ends and tri-clamps included
• Clean-in-place (CIP) function allows for easy cleaning

NO MAINTENANCE ELECTRONICS
