Vibratory Feeders with Hopper Base Diagram

A

10 in

B

24 in

C

18 in

D

28 in

E

14 in

F (Hopper Capacity)

0.9 in

Weight

33 lb

Note

All dimensions in inches. Specifications are subject to change.
