Diagram

Box Rails (BR Series) Diagram

Width Dim. "A"

8.187 in

208 mm

Thickness "B"

4.062 in

103 mm

Length Dim. "C"

Built to Customer's Specification (Up to 8')

Tap Distance Dim. "D"

Built to Customer's Specifications (12" On-Center in Backplate Standard)
