Diagram

Sheet Separators Diagram

Series

800

Height "A"

9 in

228.6 mm

Width "B"

8 in

203.2 mm

Depth "C"

3.5 in

88.9 mm

Hole Depth "D"

2.37 in

72.89 mm

Hole Width "E"

7 in

177.8 mm
