Magnetic Products, Inc.

683 Town Center Drive,

Highland, MI 48357

Tel: 248-887-5600

Email: [email protected]Website: www.mpimagnet.com

Item # STSS-0505-1.95-2.0-REN, Stack Tracker Sheet Separators (STSS Series)

List Price QUOTE

Application:

MPI’s (patent-pending) Stack Tracker is manufactured to meet the demanding needs of metal forming production environments. The Stack Tracker significantly
increases uptime by eliminating the possibility of double sheets when handling oily, sticky or pre-finished blanks in automated stamping, forming and shearing
operations.

Construction:

Powerful Rare Earth permanent magnet material is enclosed in an all-welded 100% stainless steel housing. Able to withstand demagnetizing (actual loss of only 1/2 of
1% over 100 years can be expected, under normal operating conditions.

Operation:

Simply slide the housing over the pin and attach the Stack Tracker to the side of the stack of blanks, near the top. As blanks are removed, the Stack Tracker will work
its way to the bottom of the stack, fanning individual blanks as it moves.

Benefits:
• Pneumatic safety shock prevents employee injury during handling, pallet change out and other operations
• Speeds production
• Enables easier handling of oily, sticky, polished sheets
• Improves operator safety
• Increases efficiency
Standard features:
• Powerful rare earth permanent magnet material 100% stainless steel housing
• Dual handle safety feature
• Lightweight, rugged design
• Automatic adjustment as stack decreases
Optional features:
• Special mounting available
• Replaceable wear strips

SPECIFICATIONS

4/21/2014 | Page 1 of 2
