15D1 T OUCHCOMPUTER U SER G UIDE 33
Feature Description
Ports 7 x USB 2.0 ports
1 x 12V/24V default cash drawer port (jumper selectable)
3 x RS232 serial ports
2 x 5V default/12V powered RS232 serial ports (jumper
selectable)
2 x PS/2 (keyboard and mouse)
Audio ports 1 x 3.5mm mic-in
1 x 3.5mm audio-in
1 x 3.5mm audio-out
Networking 1 x 10/100BASE-T Ethernet port (LAN RJ45)
BIOS AMI
Real-time clock Replaceable lithium-ion battery for clock
Storage 1 x 2.5-inch 80GB SATA HDD (minimum, optional second
drive)
1 Compact Flash type I (tested with Transcend, Apacer,
Kingston, and SanDisk)
Power supply Internal 12VDC universal-type power supply brick
AC input voltage: 100-240V AC
Input frequency: 50-60Hz
Input current: 2.5-5A
Max output power: 270W
DC output:
+3.3V / 5.0A
+5V / 16.0A
+12V / 12.0A
+24V / 2.3A
+5Vsb / 3A
-12V / 0.4A
