15D1 T OUCHCOMPUTER U SER G UIDE 15
Number Port Description
1 Audio Audio in (left), out (center), mic (right)
• Audio
In
• Audio Out: One 3.5mm stereo audio output jack for
connecting headphones or external powered
speakers
• Microphone Input: One 3.5mm microphone input
jack for connecting an external microphone
2 Ethernet One RJ45 Ethernet port providing LAN capabilities
3, 8, 9 USB Seven USB 2.0 type A ports
4 VGA One D-SUB VGA output port for connecting the display
head
5 Parallel Standard 25-pin connector port
6 Serial Three standard serial ports
7 PS/2 universal Mouse (left) and keyboard (right)
8 Customer display Customer display / USB 2.0; the max loading on this
port is 5VDC @ 1.5A
10 Printer power One 24V DC printer power port
11 Compact flash Standard CF port
12 Speaker power Power switch for internal speakers
13 Cash drawer RJ11, 6 position (12V/24V default)
14 Powered serial Two powered serial ports, 5V default/12V
15 Main power AC power
NOTE: The customer display, fingerprint reader, and barcode scanner are
designed to connect to the USB 2.0 ports on the I/O panel. If all three
peripherals were connected, there would be four USB 2.0 ports
remaining.
