2. Slide a card through the MSR and verify that the data is displayed in the
application window.
3. If the card ID appears in the Reader Output window, the reader is functioning.
Customer Display
You can optionally add a customer display to the 15D1 touchcomputer. Each
display has two lines of 20 characters (2x20 VFD).
The customer display can be adjusted to a 30-degree range up and down and
swivels 30 degrees side to side.
Customer
display
Display rotates 30° up
and down, and swivels
30° left to right
