Page 2
6
2
5 x #6-32 MTG holes
on a 4.656 bolt circle
9061500
9061510
MOUNTING
HOLE
PATTERN
FRONT
3.60
Base
Passage
Hole
75°
75°
75°
75°
60°
SCREW, 6-32 X 1" PPHMS MS51957-34 1 4 - 0 0 5 0 5 0 3 - 3 4
2
3
4
5
6
1
1
1
1
5
1
1
1
5
ITEM PART NUMBER DESCRIPTION
MODEL 9061500 ANTI-COLLISION LIGHT ASS'Y (UPPER)
MODEL 9061510
LOWER ANTI-COLLISION LIGHT ASS'Y ( )
ASSY, ANTI COLLISION LIGHT 90615
RETAINER, LENS
GASKET, LENS
LENS, HARDCOAT
LENS, HARDCOAT w/DRAIN
0 1 - 0 7 9 0 6 1 5 - 0 0
0 1 - 0 7 9 0 6 1 5 - 1 0
0 1 - 0 2 9 0 6 2 0 - 0 0
3 8 - 0 2 5 1 0 1 8 - 0 0
6 8 - 4 1 5 0 0 6 1 A 3 0
6 8 - 4 1 5 1 0 1 9 A 3 0
1 9 - 1 7 1 5 6 4 - 1 0 0
QTY QTY
1 1
Low power Bi-directional control signal.
Connecting to the synchronize signal of
any Whelen LED anti-collision assembly
will cause the lights to flash at the same
time.
If synchronization is not necessary, the
connection may be left open.
*
MS3112E14-5P
CONNECTOR WIRING
POS A
POS B
POS C
POS D
POS E
+28V A/C WHT
GROUND
+28V A/C RED
N/C
SYNCHRONIZE*
5
3 4
1
