ITEM PART NUMBER DESCRIPTION
ASS'Y, ANTI-COLLISION LIGHT MODEL 9058800
ASS'Y, LIGHTHEAD, 9058800
GASKET, LENS
LENS, HARD COAT
RETAINER, LENS
SCREW, 4-40 X 5/16 FHMS 100° COUNTERSINK
0 1 - 0 7 9 0 5 8 8 - 0 0
0 1 - 0 2 9 0 6 0 2 - 0 0
3 8 - 0 1 5 1 0 0 9 - 0 0
6 8 - 3 9 7 1 4 9 8 A 3 0
1 9 - 1 5 1 0 0 5 - 1 0 0
1 4 - 0 0 5 0 5 8 1 - 0 3
QTY
4
5
4
2
1
1 1
1
4
4
2
5
5
3
MS27508E8F98P CONNECTOR
POSITION A = 28VDC
POSITION B = SYNC
POSITION C = GROUND
KEY ORIENTATION
REAR VIEW
