Whelen 7117203 - Manual (Page 2)

Page 2
3 x 0.140 DIA
MOUNTING HOLE
FOR #6-32 SCREWS
MOUNTING DIMENSIONS
1.31 DIA.
1.00
.50
.820
.56
.82
1.75
.36
3
4
5
9
6
7
8
1 2
6 8 - 3 9 5 0 9 0 2 A 3 0
3 6 - 0 0 5 0 6 2 6 - 0 1
3 8 - 0 2 3 0 0 2 1 - 0 0
QTY. QTY.
0 1 - 0 7 7 11 7 2 - 0 3
0 1 - 0 7 7 11 7 2 - 0 4
PART NUMBER
1
*
*
0 1 - 0 2 7 11 7 9 - 0 3
0 1 - 0 2 7 11 7 9 - 0 4
1 1
-
1 -
1 1
1 1
1 1
1 1
1
1 1
1
3 8 - 0 1 3 0 1 0 7 - 0 0
6 8 - 2 2 9 0 0 0 5 - 5 4
1 9 - 1 7 11 2 2 - 1 0 0
1 4 - 0 0 5 0 5 0 8 - 2 7
3
1
2
8
4
5
7
6
9
7117203 POS/STROBE LIGHT, 28V (GRN)
7117204 POS/STROBE LIGHT, 28V (RED)
DESCRIPTION
LENS, CLEAR FWD POSITION LIGHT HARDCOAT
GASKET, W-1283/W-1285/A650
71110 ASS'Y, POSITION/STROBE LIGHT 28V (GRN)
71110 ASS'Y, POSITION/STROBE LIGHT 28V (RED)
LENS, RED/COATED A612 RC
RETAINER, LENS MODEL 71110 IRIDITE/COMPLETE
SCREW, 6-32 5/16 PFHMS CSINK MS51959-27
GASKET, A427-4 1/4" THICK
ASS'Y, FLASHTUBE 6.00" LEADS W/GROMMET
ITEM
