Parts explosion, Top plate – SAF-HOLLAND XL-FW488 FW2800 and FW2900 Series Hydraulic Elevating Fifth Wheel User Manual
Page 13
XL-FW488 Rev A
13
XA-2801-AX-1
TOP PLATE
Parts Explosion
ITEM PART NO.
QTY DESCRIPTION
14 XB-T-69-A
3
Lock Nut, 1/2˝-20
15 XB-PW-1732-1-116 3
Washer, 1/2˝
16 XA-1705-11
1
Cam Plate S/A
17 XB-CX-58-F-134
1
HHCS, 5/8˝-18 x 1-3/4˝
18 XA-2524-R-13-X
1
Air Cyl. S/A for XA-2801-AX-1
19 XB-01996
1
90° Street Elbow
20 XB-2083
2
HHCS, 1/2˝-20 x 1-3/4˝
21 XB-T-49
1
Washer, 1/2˝
22 XA-1029
1
Roller
23 XB-GT-13-1
1
Extension Spring
24 XA-1704-X
1
Lock Set
25 XB-10267
1
Washer, 9/16˝
ITEM PART NO.
QTY DESCRIPTION
1
XA-1707-16
1
Handle S/A Release
2
XB-1028-1
1
Spring
3
XB-5
2
Cotter Pin, 1/4˝ x 2˝
4
XA-3544-1-A
1
Handle S/A
5
XA-1703-F
1
Yoke
6
XA-1313
2
Lock Pin
7
XA-3528
1
Lock Bar
8
XB-2149
1
Torsion Spring
9
XA-1507-1
1
Cam Roller
10 XB-1030-1
2
Washer
11 XB-21-S-500-2750 1
Roll Pin
12 XB-1505
1
Spring
13 XA-1706-1
1
Yoke Shaft
4
13
12
5
11
7
8
10
16
9
10
17
20
25
22
21
14
20
14
18
15
2
1
24
23
3
3
6
6
15
15
14
19
