Keyboard Outline Drawing (Optional)
Description:
Outline:
87.2 x 14 x 12.7 mm
Top Layer High (Max): 8 mm
Bottom Layer High (Max): 3.5 mm
Board thickness: 1.2 mm
Four Screw Holes: Φ 2.5 mm
Demo Kit Outline Drawing (Optional)
Description:
Outline:
83.75 x 25 x 19.7 mm
Top Layer High (Max): 15 mm
Bottom Layer High (Max): 3.5 mm
Board thickness: 1.2 mm
Four Screw Holes:
Φ
2.5 mm
