HSA 400/402 Series • Packaging for Shipment
Packaging for Shipment, cont’d
B-8
11
.
HSA 400 US/domestic version only
. These smaller HSAs
in the foam shells do not fit snugly in the shipping carton.
Pad either side with the extra foam that was included in
the return kit. Insert the foam vertically in the carton’s
corners on one side of the carton and horizontally on the
other side of the carton (figure B-8).
Vertical Foams
Horizontal Foams
Figure B-8 — Padding the carton with foam, HSA 400
US/domestic version only.
12
.
Close the shipping carton and seal it with high quality
shipping tape.
13
.
Ship the HSA to Extron using a reputable shipping
company.
